Picture of Hydratail with Mini-Deck and Drop

Trailer

Hydratail with Mini-Deck and Drop

The Ledwell Hydratail Trailer with Mini-Deck and Drop adds another option for equipment hauling. Large, tall pieces of equipment often necessitate a lower bed to be transported. With the Ledwell Drop Model Trailer, we provide another 6 to 10 inches in load height.
Picture of Hydratail with Mini-Deck and Drop Picture of Hydratail with Mini-Deck and Drop Picture of Hydratail with Mini-Deck and Drop Picture of Hydratail with Mini-Deck and Drop
Picture of Hydratail with Mini-Deck and Drop
  • GVW: 35 or 50 ton
  • Length: 48'; 10' front deck, 30' main deck
  • Mini-Deck: 10' built-in ramp from main deck
  • Tail: 8' hydraulic tail w/ 5' fold under
  • Width: 102"
  • Drop: Lower deck drops 6" – 10", depending on application
  • Also available in 50 ton model
  • Hydraulic winch available in 12,000# or 20,000#
  • Wireless Remote Control
  • Manually operated controls
  • All steel construction; fabricated beams are built with high-strength steel
  • Interior or exterior beams
  • Deck can be steel over wood or hardwood deck
  • Ledwell manufactured hydraulics
  • DOT lights, reflectors and mud flaps
  • Emergency reflectors supplied
  • Fire extinguisher
  • 3M conspicuity tape
  • Landing gear
  • Traction surface
  • Side steps
  • A variety of tie-down options: D Ring, Keyslot, V-chain stops, stake pockets and rub rail
  • Toolboxes can be recessed or under-mounted
  • Spring or air-ride suspension
  • Multiple tire options
  • Wiring harness lighting system
